Industrial Touch Panel PC – TPC-DCM121C1
TPC-DCM121C1 for Industrial HMI Applications
Fanless Industrial Touch Panel PC for Automation, Visualization, and Process Control
TAICENN TPC-DCM121C1 is designed for industrial and professional installations where a compact, robust, and fanless Touch Panel PC with stable operation and modern touch functionality is required. The model is well suited for HMI solutions, automation, process control, and visualization, where reliability and long service life are important requirements.
TPC-DCM121C1 is a 12.1" industrial Touch Panel PC with XGA resolution and 10-point capacitive multitouch. It combines a slim fanless design with an Intel® Bay Trail J1900 quad-core processor, making it well suited for both operator interface solutions and industrial systems focused on stable and energy-efficient operation.
With its rugged enclosure and IP65-rated front, TPC-DCM121C1 is designed for operation in demanding industrial environments. The system supports both panel mounting and VESA mounting, allowing flexible integration into machines, control cabinets, and industrial workstations.
TPC-DCM121C1 offers up to 8 GB DDR3L RAM, mSATA storage, and a wide range of connectivity options, including 2 x Gigabit LAN, 4 x USB, 1 x COM, HDMI, and audio. In addition, optional wireless expansion is available for features such as 3G/4G, Wi-Fi, and Bluetooth.
With its wide 9–24V DC input and support for industrial expansion options, TPC-DCM121C1 is designed for installations where stable operation, flexible integration, and high functionality are essential. For companies working with industrial automation, HMI, and visualization in production environments, the model provides a strong foundation for building a stable and reliable solution.
Key Features
- 12,1" XGA display
- 10-point capacitive touch
- Intel® Bay Trail J1900
- IP65 front and fanless design
- Flexible I/O and wireless expansion options
Datasheet
TPC-DCM121C1
Part of TAICENN TPC-DCM-serieTPC-DCM121C1 is part of the TAICENN TPC-DCM Series, where the differences typically lie in display size, processor, and configuration, while the industrial fanless design is shared across the series. |
Additional information
| Contact us: | Email: email@nordtechnology.dk |
|---|---|
| Design | Aluminium, Compact, Fanless, High-Brightness, Rugged |
| Display size | 12.1” |
| Mounting | Panel Mount, VESA Mount |
| Ingress protection | IP65 |
| Operating Systems | Linux, Windows |
| Processor | Intel® Celeron / Pentium |
| Touch | 10-point capacitive |
