Special Controller for Machine Vision, KMDA-5611 og KMDA-6611

Special Controller for Machine Vision, KMDA-5611 og KMDA-6611

In the context of vigorously developing intelligent manufacturing, the new generation of information technology with AI as the core is accelerating its integration in the industrial field. Machine vision is one of the typical applications of AI technology in industry.

Machine vision is a comprehensive technology. A typical machine vision software system includes image capture, light source system, image digitization module, digital image processing module, intelligent decision-making module, and mechanical control execution module. In the field of machine vision, a dedicated controller using deep learning and computer vision technology can quickly identify and locate target features in captured images, accurately recognizing objects, vehicles, faces, etc. In the manufacturing industry, machine vision software, supported by dedicated controllers, can realize image acquisition, quality control, automated production, and other functions, thereby improving production efficiency, reducing costs, and minimizing human errors. Additionally, dedicated machine vision controllers are widely used in target detection and recognition, image inspection, positioning measurement, product sorting, and play an important role in predictive maintenance.

JHCTECH adheres to the strategic goal of “Scenarios empowering product innovation” and has been committed to providing product solutions that meet scenario needs for users in various industries. The machine vision dedicated controller KMDA-5611/6611 have been developed in response to this.

Let’s follow our steps to see the impressive features of these two star products!

KMDA-5611/6611 high-performance box computer

KMDA-5611/6611 are high-performance box PC. The KMDA-5611 adopts the H310 chipset, equipped with Intel® 8th/9th generation Coffee Lake series processors; the KMDA-6611 uses the H420E chipset, equipped with Intel® 10th generation Comet Lake series processors. They offer rich I/O functions, and their moderate size makes them suitable for industries and fields such as machine vision and industrial control.



Multi-port POE+ network port design

  • Simultaneous transmission of data and power, reducing the number of system cables and lowering wiring costs
  • Supports connection of more vision components (high-definition industrial cameras, smart cameras, encoders, light source controllers, etc.)
  • Compliant with IEEE 802.3at standard, supports advanced management functions such as remote device power control, energy consumption monitoring, fault isolation, and improving system intelligence management.
Multi-port POE+ network port design

High-current power supply for USB3.0

  • 8-channel high-current power supply USB3.0 interface can provide sufficient power support to more high-power devices (such as high-performance industrial cameras, sensors, LED lighting, etc.), especially suitable for machine vision applications requiring high-brightness illumination or high-speed image capture.
  • Achieve fast data transmission to meet the processing requirements of large amounts of data in the field of machine vision, plug and play, convenient for device connection and replacement.
JHCTECH-High-current power supply

32-channel high-speed isolated DIO

  • 32-bit Isolated DIO, 16-bit DI with 2.5KV Optical Isolation, supports switchable PNP and NPN modes; 16-bit DO with 2.5KV optically isolated Darlington output, built-in matching resistors, selectable according to different drive currents
  • Effectively prevents ground loops, noise interference, voltage surges, etc., enhancing the overall anti-interference capability of the system and the reliability of data transmission
  • Pulse cycle reaches 2ms/pulse wave, enabling fast response and precise control of various digital devices such as triggers, relays, motor drivers, and accurately collecting digital signals from sensors, encoders, and other equipment.
32-channel high-speed isolated DIO

Modular design with easy CPU upgrades

NODE core module + PIB function carrier board + IO expansion daughter card combination design, allowing easy CPU upgrades from 6th to 10th generation

CPU-Modular design with easy CPU upgrades

I210AT network chip, compatible with various operating systems

I210AT network chip, high stability and versatility, compatible with various operating systems

I210AT network chip, compatible with various operating systems

Single-sided interface, simplified application wiring

  • Makes cable connections, equipment installation, and subsequent maintenance more intuitive and straightforward
  • Helps reduce equipment depth, especially suitable for space-constrained industrial environments such as compact control cabinets, embedded workstations, or wall-mounted installation scenarios. This can optimize internal chassis space utilization, providing more room for arranging other critical components.
Single-sided interface

Diverse installation options

Diverse installation options

Market Directions

Machine Vision

Machine Vision

  • Logistics Vision
  • Sorting photovoltaic Vision Inspection
  • Intelligent Qauality Inspection Machines
  • Automotive Manufacturing Inspection
JHCTECH- Industrial Manufacturing

Productionindustri

  • Industrial Robotic Arms
  • Laser Cutting Machines/Engraving – Machines/CNC Machining Centers
  • Dispensing Machines/3D Printers Distributed control systems
  • Distributed control system (DCS)

This news was first published on the JHCTECH website

Find more Compulab products on our product site

Other JHCTECH products

Reliable, industry-grade devices for demanding environments

Nord Technology is a distributor for JHC Technology

More on JHCTECH

JHC Technology has been producing robust industrial hardware for more than 20 years.

Contact us and book a meeting:

Kevin Peter Gade CEO Nord Technology

Kevin Peter Gade

As always, our door, telephone or mail box is open, should the above give rise to questions or simply for a chat and sparring.
Send a Email
Or contact us by phone at +45 7027 0415

Sign up for our newsletter to be updated about the new products and solutions we offer.

IOT-DIN-IMX8PLUS IoT Edge Gateway

IOT-DIN-IMX8PLUS IoT Edge Gateway

Compulab Press Release – Compulab’s IOT-DIN-IMX8PLUS is a modular DIN rail IoT Edge Gateway optimized for industrial applications

Compulab introduces IOT-DIN-IMX8PLUS – an industrial IoT gateway, offering rich functionality and exceptional modularity in a miniature, DIN-rail housing. Built around Compulab’s own UCM-iMX8M-Plus System-on-Module, IOT-DIN-IMX8PLUS features the NXP i.MX8M Plus SoC coupled with up-to 8GB RAM and 128GB storage.

The base IOT-DIN-IMX8PLUS unit provides a wide range of features required in typical IoT control and monitoring applications:

      • Worldwide LTE/4G modem and GNSS
      • Dual Gbit Ethernet ports
      • USB3.0, RS485 and RS232 ports
      • CAN bus, 2x DI + 2x DO
      • Hardware watchdog and TPM

A Truly Modular Solution

Each IoT project presents different connectivity requirements that cannot be addressed with a single hardware configuration. To allow users to easily adapt the gateway to different use cases and installations, IOT-DIN-IMX8PLUS can be expanded with an assortment of stackable I/O Expansion Modules:

      • 4-port RS485 module
      • 4-port RS232 module
      • 16 DIO (8 outputs + 8 inputs) module
      • Analog input module
      • 802.11ax WiFi + Bluetooth 5.3 module

I/O Modules are interconnected using the Compulab proprietary StackLink expansion interface. Up-to eight modules can be stacked, allowing the user to implement the following additional functionality in a single gateway:

      • up-to 12x RS485 | RS232 ports
      • Up to 64x DIO
      • up-to 8x ADC channels
      • WiFi 802.11ax and Bluetooth 5.3

I/O modules are automatically detected and configured on system boot, enabling completely seamless module installation and removal.

Additional I/O modules are in development. Custom, application specific modules will be offered on demand.

Optimized for Industrial Deployment

IOT-DIN-IMX8PLUS is designed to address the requirements of IoT integration in industrial environments:

      • High reliability and 24/7 operation
      • Wide temperature range of -30C to 70C
      • 5 year warranty and 15 year availability
      • Customer O/S and application imaging service
      • ODM rebranding with custom logo and labeling

Software Support

Compulab provides IOT-DIN-IMX8PLUS with ready-to-run Debian Linux with built-in Docker support and easy-to-use deployment tools, allowing customers to focus on application development.

Customers who prefer to configure a custom O/S image can leverage the IOT-DIN-IMX8PLUS Yocto BSP which includes Linux kernel 6.1, Yocto Project 4.2 and U-Boot boot-loader. OTA updates are supported using a pre-configured Mender layer.

In addition, IOT-DIN-IMX8PLUS supports popular IoT frameworks such as Docker, Microsoft Azure IoT and Node-RED.

Specifications

CPU i.MX8M Plus, quad-core ARM Cortex-A53, 1.8GHz
RAM Up to 8GB LPDDR4
Storage Up to 128GB, eMMC flash, soldered on-board
Network 2x Gbit Ethernet ports
Worldwide 4G/LTE CAT4 cellular modem
USB 1x USB3.0 port, type-A connector
Serial 1x RS485 port
1x RS232 port
CAN bus 1x CAN bus
Digital I/O 2x DOUT + 2x DIN
Expansion I/O StackLink expansion interface supporting up-to 8 I/O modules:
up-to 12x RS485 | RS232
up-to 32x DO + 32x DI
up-to 8 ADC channels
RTC Real time clock with back-up battery
Security TPM 2.0, Infineon SLB9673
Watchdog Hardware watchdog
Debug Serial console via UART-to-USB bridge
Power Supply 12V-24V DC
Dimensions Base gateway: 110 x 30 x 95 mm
I/O modules: 110 x 20 x 95 mm
Housing DIN rail housing
Cooling Passive cooling, fanless design
Temp. range -30C to 70C

Availability and Pricing

IOT-DIN-IMX8PLUS is available through Compulab’s worldwide distribution channels.

IOT-DIN-IMX8PLUS is offered at a variety of configurations starting from $145 for volume orders.

Detailed ordering and pricing information is available at IOT-DIN-IMX8PLUS product page.



Compulab products

Other Compulab products

Find more Compulab products on the Nord Technology product site

Compulab - read more about the company and their products

More about Compulab

CompuLab is a leading manufacturer of System-on-Module and Computer-on-Module products, IoT gateways and fanless industrial computers.

Contact us and book a meeting:

Kevin Peter Gade CEO Nord Technology

Kevin Peter Gade

As always, our door, telephone or mail box is open, should the above give rise to questions or simply for a chat and sparring.
Send a Email
Or contact us by phone at +45 7027 0415

Sign up for our newsletter to be updated about the new products and solutions we offer.

Nord Technology enters into a distribution agreement with JHC Technology

Nord Technology enters into a distribution agreement with JHC Technology

A partnership that benefits our customers

We have entered into a stronger collaboration and partnership with our supplier JHC Technology. Our goal is always to expand our portfolio of robust, industrial IT solutions and meet our customers’ growing needs for quality and delivery reliability. With more than 20 years of experience in the production of industrial computers, JHC provides a comprehensive range of mission-critical solutions for a variety of industries. The range includes everything from embedded box PCs and industrial panel PCs to edge AI GPU box PCs, automation controllers and single-board computers (SBCs).

Products that cover a wide spectrum of needs

The products are characterized by their unique, robust design and are particularly well suited for complex and challenging applications within automation, environmental monitoring, intelligent transport, robotics, medical systems and artificial intelligence. Their two-year product warranty and long-term supply security make them an ideal choice for companies with critical industrial needs. Contact us to learn more about how, together with JHC, we can solve your most complex technology challenges.

JHC Technology is committed to providing the highest quality products and offers a 2-year product warranty as well as long-term supply support. We look forward to offering these first-class solutions to our customers and strengthening our collaboration with JHC Technology.



A small selection of JHCTECH products



JHC Technology products

See more JHCTECH products on the Nord Technology product site.

More on JHCTECH

Read more about the company JHCTECH, their history and primary focus areas.

Contact us and book a meeting:

Kevin Peter Gade CEO Nord Technology

Kevin Peter Gade

As always, our door, telephone or mail box is open, should the above give rise to questions or simply for a chat and sparring.
Send a Email
Or contact us by phone at +45 7027 0415

Sign up for our newsletter to be updated about the new products and solutions we offer.

Strong strategic partnership between NORD Technology A/S and PROINFO A/S.

Strong strategic partnership between NORD Technology A/S and PROINFO A/S.

New partnership that creates a world of possibilities

We can now lift the veil on the fact that we are further strengthening our presence in Jutland. We have formed a strategic partnership with PROINFO A/S, which, among other things, has great expertise in data centers, IT operations, IT support, Microsoft technologies and, of course, good service. The new partnership opens up a world of possibilities.

Here’s what you can expect:

Strengthened technical expertise:

We now have skilled technicians located in Jutland. Together with our employees on Zealand, this gives us a wider range of skills and the opportunity to solve even the most complex tasks.

Increased customer service:

We can now cooperate with PROINFO and help each other’s customers. This means that our customers get even better service and support.

Innovative solutions:

By combining our resources and knowledge, we can develop innovative solutions that meet our customers’ needs.

Compliance:

Direct access to highly specialized staff within IT security, GDPR, NIS2 and other compliance areas.

We look forward to working closely with PROINFO and creating value for our mutual customers. Do you have questions or would you like to hear more about our new partnership?

Contact Kevin at Nord Technology A/S:

Contact Jacob Just at PROINFO A/S:

Together we create the solutions of the future!

SolidRun Launches Bedrock R8000 – Future Proof Edge AI

SolidRun Launches Bedrock R8000 – Future Proof Edge AI

Press release from SolidRun – SolidRun launches Bedrock R8000 – a fanless IPC with AMD RYZEN™ embedded 8000 for generative AI and AI inferencing at the edge

SolidRun has announced the world’s first industrial PC based on the new AMD Ryzen™ Embedded 8000 series with support for multiple Hailo-10™ and Hailo-8™ AI accelerators. The combination of AMD Ryzen™ AI and Hailo AI accelerators enables unprecedented Generative AI and AI Inferencing capabilities of over 100 TOPS in a compact and ruggedized x86 edge device.

AMD Ryzen™ Embedded 8000 processor contains a 8C/16T Zen4 CPU (up to 5.1 GHz), Radeon 780M GPU with 6 WGPs/12 CU, a 16 TOPS NPU and AMD PRO technologies for enhanced security, manageability and reliability. Ryzen Embedded 8000 has an extended longevity of 10 years. Bedrock R8000’s unique modular design brings out the full range of the powerful I/O, including up to 96 GB DDR5-5600 ECC, x20 PCIe Gen 4, four 4K displays and dual USB4 40 Gbps.

Bedrock R8000 is designed in the highly-acclaimed Bedrock form factor, exhibiting remarkable passive cooling capability which allow operation at full industrial temperature range of -40ºC to 85ºC. Bedrock R8000 fits seamlessly into the modular ecosystem of the Bedrock family and can be configured using the same Networking & I/O boards (NIO), Storage & Extension boards (SX) and Power Modules (PM).
SolidRun is introducing with Bedrock R8000 new modules – NIO R8000 4X25 with 4x 2.5 GbE ports and USB4, and PM-1248 a cost effective power module supporting 12V-48V DC in.

Focus on Edge AI

“Edge AI is a rapidly-growing market that redefines hardware requirements.” said Irad Stavi, IPC Product Line Manager at SolidRun. “Bedrock R8000 stands out in addressing current and future requirements of Generative AI and AI Inferencing applications by offering best-in-class performance, unmatched scalability and modularity, reduced time-to-market thanks to standard PC operating systems, software stacks and devices, all in an extremely ruggedized, compact, energy efficient, field proven and cost effective platform. SolidRun is committed to continue enhancing the Bedrock ecosystem and will introduce more groundbreaking features later this year.”

Bedrock R8000 features

Bedrock R8000 is offered with AMD Ryzen™ Embedded 8845HS, AMD Ryzen™ 9 8945HS and other APUs in Ryzen 8000 “Hawk Point” family. CPU power can be precisely adjusted in BIOS in an extremely wide range between 8W – 54W. For Edge AI workloads, up to 3 AI accelerators can be installed with support for both the Generative-AI optimized Hailo-10™ and AI-Inferencing optimized Hailo-8™.

RAM and storage are modular with 2x SODIMMs supporting 96 GB DDR5 ECC/non-ECC, and 3 NVME 2280 PCIE Gen4x4 devices, including enterprise-grade NVME with power loss protection (PLP). RAM and storage are conduction-cooled for reliable operation at extreme temperatures.

Multiple I/O configurations are available including up to 4 displays comprising HDMI 2.1 + 3x DP 2.1, up to 4 2.5 Gbit Ethernet ports (Intel I226), optional WiFi 6E + BT 5.3, 5G or LTE modem, USB4 type-C, 4 USB 3.2 ports and a console port. All I/O is conveniently organized on a single face to simplify integration.

Bedrock R8000 supports all major PC operating systems, including most Linux distributions, Windows Desktop, Server and IoT.

Power, mechanical and thermal design

Bedrock R8000 electronic design is modular, SoM based. Power input is by an optional Power Module (PM) for supporting various deployment use cases. Three PM options are currently available 12V-24V, 12V-48V and 12V-60V.

The enclosure is made of heavy-duty machined aluminum with an anodized finish. It is offered in 3 variants – 1.0 liter enclosure for dissipating up to 30W by convection, 1.6 liter for 60W and an 0.6 liter “Tile” variant for conduction cooling. The enclosure is ideal for DIN-Rail mounting with a specially designed zero-force locking bracket.

Bedrock R8000 fanless design can handle up to 60W, which is over 3 times the cooling capacity of typical fanless PCs of similar size. Cooling innovations include liquid metal TIM, 360º stacked heat pipes, double layer chimney effect heat exchanger and thermal coupling of all internal units.
The system operates reliably over a temperature range of -40ºC to 85ºC.

Bedrock R8000 datasheet



Other SolidRun Bedrock products

See other Bedrock R7000 Edge AI products

More about SolidRun

Nord Technology has recently made a distributor agreement with SolidRun. SolidRun is known for its innovative and ground-breaking products.
